Our South Atlantic S 301 works according to the servo pendulum rudder system. It uses the Wind and the force of the water flowing past the ship in motion.
"Don McIntyre made the South Atlantic S 301 the standard Self Steering WindVane on his new Mini Ocean Racer fleet! "
South Atlantic S 301, is specially designed for small ocean-going yachts from 18 ft. To 30 ft.
Advantages of our S 301
Self Steering Wind Vane
" Adjustable vane (for strong or light wind)
" Vane fixing in central position
" Adjustable power transmission
" Easy to start and stop operating
" Lift up swinging rudder, + - 170 degrees
" Protection against overloading
"Autopilot option: a pin fitting for an Autohelm or Simrad cockpit autopilot is provided as standard on the windvane arm
" Detachable auxiliary rudder
Adaptability
"Length of air vane mast, pendulum shaft and tiller arm customised
to fit each individual boat.
Strength and Durability
South Atlantic, uses a 100% sea water resistant alloy.
South Atlantic grants a lifetime guarantee against damage in the
material (aluminium).
Materials
" Sea water resistant aluminium,
" POM bearings.
" Servo rudder, Wood epoxy coated
" 6mm polycarbonate vane
Weight
ca. 13 Kilos
Bearings
"We use sliding bearings: they need no upkeep and run
softly.
Demand for spare bearings is almost man-existing!
LOA
Series S-301 : up to 9 m / 30 ft
Displacement
Series S-301: up to 2900 kg
